Double K 401 Power Groomer

(Click on image for Larger view)

Item# Part# Description Price Buy
1 537 Cord - 12' 10.27

2 426 Quick Tie 4" Flat Red
3 481A Left Side Housing
4 482A Right Side Housing
5 445 Hsg. Cable Adapter
6 479 Acorn Nut .95

7 423-1 401 Clipper Mtr. 114.42

8 5540 1/4" Female Term. .62

9 488 Rear Mtr Support
10 490 Washer
11 412 Rotary Rheostat Sw. 29.98

12 5517 Self Tapping Hex Nut .62

13 402 Rotary Knob 4.79

14 9042 Rectifier 18.00

15 534 Cord Grommet
16 422 Set Screw 10-24x.25 .62

17 485 Screw 8-32x.750
18 10078 Locknut 8-32 .62

19 484 Screw 8-32x2.00
20 10019 Self Tapping Screw 6-32x1/2 .62

21 5533 6-32 Locking Nut .62

22 575 Safety Hook 2.84

23 442 Black Plastic Chain
24 483 Shakel
25 545-05 5' Cable 59.25

25 545-07 7' Cable 68.79

25 545-10 10' Cable 78.24

25 545-12 12' Cable 87.68

25 545-15 15' Cable 97.11

25 545-20 20' Cable 109.60

26 516 Shaft Lever Drive 15.95

27 505 Shaft Bearing .25x.60 9.69

28 506 Lever Ball Bearing 11.37

29 592 Large Flywheel 7.30

30 591 Small Flywheel 7.20

31 411 Set Screw 10-24x.5 .62

32 409 Ret. Ring .250 .72

33 507 Ret. Ring .125 .72

34 512 Clipper Bottom 27.56

35 3025 Latch Hook 5.25

36 515 Ball Bearing 7-32 1.43

37 514 Clampball Spring 3.72

38 444 Fillister Low Pro 6-32x5/16
39 480 Washer .42

40 598 Lever w/Bushing 3.75

41 508 Felts .84

42 517 Clipper Top 18.00

43 502 Handpiece Cover Plate 4.54

44 501 Screw 6-32x5/16
(Cover Plate Screw)		 .55

45 431 Lever Bushing .62

46 418 Spring Clip 9.75

47 2091 Aluminum Rivet
48 492 Spacer
49 491 Plastic Spacer
50 494 Power Clipper Decal
51 493 Screw 6-32x312lg
52 10307 Duct Tape
53 513 Screw 6-32x.50 .62

54 510 Hinge 9.68
